CG ATEX PA 50pc P-TEC Ex KL M16 (3-8) black with long thread
The shock resistant strain relief cable gland for cold exposure and applications in hazardous areas.
- Equipment group II
- Category 2 and 3
- Atmosphere G/D
- Area 1, 2, 21 and 22
Colour
Black
Material
Plastic
Material quality
Polyamide (PA)
Surface protection
Untreated
Glass-fibre reinforced
No
Shock resistant
No
Bend radius protection/trumpet flare
No
With locknut
No
Flat cable coupling
No
Separable screw gland
No
Type of sealing
Sealing ring
Multi seal area
No
Operating temperature
-35...+95 °C
Degree of protection (IP)
IP68
Halogen free
Yes
UV-resistant
No
Explosion-tested version
Yes
For Ex-zone gas
1, 2
For Ex-Zone dust
21, 22
EMC-version
No
Fire behavior
standard
interior hot melt adhesive
No
sealing quality
1 Artikel
Item
Thread type
Nominal thread size metric/PG
number opening
Pitch thread mm
Thread length mm
Wrench width mm
Suitable for cable diameter mm
RAL-number
Availability
SU
Price / SUexcl. VAT
- Item 935353117Thread type MetricNominal thread size metric/PG 16number openingPitch thread
mm 1.5Thread length
mm 15Wrench width
mm 19Suitable for cable diameter
mm 3...8RAL-number 9005AvailabilitySU 50 StkPrice / SU excl. VAT
This item is available in 40 other versions.
